Details
Brand
AIRpipe
Maximum Working Pressure bar
13
Working Temperature
-20°C to 70°C
Thread Size
1/2"
Outside Diameter A mm
20
Thread Gender
Female
Description
1/2" Female x 20mm Outside Diameter, Aluminium Ring Main System 4th Generation, Female x Tube, Brass, Ball Valve, Working Temperature -20°C to +70°C, Maximum Working Pressure 13 bar, AIRpipe
4th Generation. Connection Technology. Airpipe, the 4th generation of pipe connection design uses pipe clamps, surface sealing ring and convex pipe as whole parts, which achieves a quick fit with excellent sealing. Compared to an O-type sealing ring, this AIRpipe 4th generation of sealing ring upgrades to surface contact sealing: performance is more reliable and life time doubled compared to line type sealing. Conforms to PED 2014/68/EU (replacing 97/23/EC) and certified by TÜV Rheinland.
