Metal Work SS CYL 20MM DIA X 125MM Stroke
Product Code: W1800200125- Buy Price(exc VAT)
Details
Stroke Length mm
125
Brand
Metal Work
Working Temperature
-10°C to +80°C
Barrel Material
AISI 304 Steel
Maximum Working Pressure bar
10
Magnetic
Magnetic
Bore Size mm
20
Number of Gangs
Yes
Material
Stainless Steel
Piston Rod Material
AISI 316 Steel
Specification
20mm Bore x 125mm Stroke, Magnetic, ISO 6432 Mini Cylinder, Double Acting, AISI 316 Steel Piston Rod, AISI 304 Steel Barrel, Working Temperature -10°C to +80°C, Maximum Working Pressure 10 bar, Metal Work Huge Savings! Available for a limited time - while stock lasts
Technical Specifications: ISO 6432 stainless steel micro-cylinders are available in various versions with a wide range of accessories. With or without magnet execution. Double-acting, single or through-rod. Gaskets: polyurethane or FKM/FPM (for high temperatures). Fixing accessories. Fluid Lubricated or non-lubricated air.
Additional Variants
Product Name
Product Code
Working Temperature
Stroke Length mm
Bore Size mm
List Price
-10°C to +80°C
100
20
Available to Order
-10°C to +80°C
80
20
Available to Order
-10°C to +80°C
125
25
Available to Order
-10°C to +80°C
25
16
Available to Order
-10°C to +80°C
320
20
Available to Order
-10°C to +80°C
160
25
Available to Order
-10°C to +80°C
320
25
Available to Order
-10°C to +80°C
160
20
Available to Order
-10°C to +80°C
10
16
Available to Order
-10°C to +80°C
25
20
Available to Order
-10°C to +80°C
125
16
Available to Order
-10°C to +80°C
250
16
Available to Order
-10°C to +80°C
400
20
Available to Order
-10°C to +80°C
320
16
Available to Order
-10°C to +80°C
200
20
Available to Order
-10°C to +80°C
200
25
Available to Order
-10°C to +80°C
10
20
Available to Order
-10°C to +80°C
10
25
Available to Order
-10°C to +80°C
50
20
Available to Order
-10°C to +80°C
160
16
Available to Order
